Multibeam Sonar Systems
Ultra-compact wideband multibeam sonars for subsea and surface platforms
Two products series of multibeam sonar/echo sounder.
The NORBIT WINGHEAD series provides ultra high resolution bathymetry and imaging.
NORBIT WBMS series which offers industry leading resolution in the worlds most compact, low power platform. Use the illustration to find multibeam sonar system to cover your needs.
Integrated Bathymetric Systems
Bathymetry systems
Advanced Monitoring Systems for dredging, construction and renewables
Forward looking (FLS) wide area imaging
Advanced Imaging systems for Obstacle Avoidance/MCM
Above Water Laser (NORBIT iLiDAR integration option)
Introducing the NORBIT WINGHEAD Multibeam Echo Sounder Family
*
Introducing the NORBIT WINGHEAD Multibeam Echo Sounder Family *
NORBIT WINGHEAD Multibeam Echo Sounder Family
The NORBIT WINGHEAD series are the most high performance sonars available on the market, designed for used in the most challenging conditions and applications.
The WINGHEAD series is based on NORBIT’s unique cylindrical sonar technology, featuring high resolution, wide swath, Low Power and ultra portable form factor.
Multibeam Sonars for Every Application
Ultra High Resolution Bathymetric System
3D, 4D, Medium range & Depth Sea rated
GNSS/INS integrated solution for surface vessels
Extended Range & Long Range
Dual Head for Ultra wide swath or Highe density surveys
Stand alone solution for subsea vessels such as ROV & UUV
Also Hull Mount
NORBIT WINGHEAD Multibeam Echo Sounder VIDEOS
NORBIT WBMS Multibeam Echo Sounder Family
*
NORBIT WBMS Multibeam Echo Sounder Family *
NORBIT WBMS Multibeam Echo Sounder Family
The Ultra Compact Wideband Multibeam Sonarsdesigned for used in the most challenging conditions and applications.
The WBMS Sonar series is the most compact sonars designed for use on all platforms. With low power consumption, the system is suitable to operate from battery.
NORBIT’s wideband multibeam technology facilitates long range real-time data collection and at the same time achieves high resolution data.
Bathymetric Echo Sounders
Multibeam sonar for High Resolution Bathymetry in all conitions
Multibeam sonar for High Resolution 3D & 4D Bathymetry
Multibeam sonar for rapid Bathymetry surveying in protected waters
Stabilised Wideband Multibeam Sonar
Wideband Multibeam 3D & 4D for high-resolution 3D imagery ond 4D experience.
Wideband Multibeam for high-resolution Bathymetry. Avaible in depth ratings down to 6000 m
Wideband Multibeam for high-resolution Long Range Bathymetry
Dual Head Multibeam
NORBIT WBMS Multibeam Echo Sounder Videos
NORBIT CARBON FIBRE “PORTUS” MOUNTING POLE
PORTUS Mounting Pole is built specifically for NORBIT’s integrated sonar systems.
The Mounting Pole fits in a single airline checked luggage case. With a combined weight of 60lbs/27kg, including wheeled hard ski case, it is safely transported to your next vessel of opportunity and set up by a single person.
With a combined weight of 60lbs/27kg, including wheeled hard ski case, it is safely transported to your next vessel of opportunity and set up by a single person. May be setup without tools and on nearly any vessel.
Setup, power on and explore more!
Designed specifically for NORBIT integrated Systems
Corrosion Resistant & Fully Hydrodynamic
Flex-Free Carbon Fibre
Collision Kick-Up - Survey at 8 knots
Ultra-Lightweight, Complete kit: 18.6kg (41lbs)+Case 8.6kgs (19lbs)
Airline Accepted Single Checked Luggage Piece
Ultra-Fast Mobilisation – Repeatable Offsets/Patch Test
Built-In Cable Protection/Management
